PURLIN

C & Z Sections are secondary structural members used between the main beams of the steel structure. Because of their light weight, hight quality, durability and lower total cost, these purlins are the best alternative to the equivalent standard steel sections

C Purlins

Our range C purlins are light in weight and perfect for simple span construction. The plane surface of this purling on one side has made it a preferred material for cladding due to its easy installation on concrete structures or steel. C Purlins are horizontal structures that are used to support the load from the roof deck or the sheathing.

Features

  • Abrasion & corrosion resistance
  • Easy installation
  • Optimum quality
  • High tensile strength

Advantages of C Purlins

  • High durability, versatility and uniform quality
  • Fast to erect and easy handling
  • Purlin erection is easier than others
  • Low transportation cost due to decreased weight
  • Close tolerances on sectional sizes due to process of cold roll forming
  • No side drilling/cutting required
  • Ability to span length
  • Assured dimensions and straightness

Specifications

Web Flange Lip Thickness
80 60 20 1.6 to 3mm
100 60 20 1.6 to 3mm
125 60 20 1.6 to 3mm
150 60 20 1.6 to 3mm
160 60 20 1.6 to 3mm
180 60 20 1.6 to 3mm
190 60 20 1.6 to 3mm
200 70 20 1.6 to 3mm
230 80 20 1.6 to 3mm
250 70 20 1.6 to 3mm
280 60 20 1.6 to 3mm
300 50 20 1.6 to 3mm

Z Purlins

Our purlins are crisp and clean in design and do not allow the scope of inaccurate lengths. Z Purlins are made using cold-formed or rolled sheets for supporting roof. The flexible shape of these beams facilitates various designs solutions. These purlins are extensively used in huge roofing solutions such as godowns, workshops, industrials sheds and many more. The range is known for saving upto 50% on structural sheet in comparison with hot rolled angles.

Advantages of z Purlins

  • High durability, versatility and uniform quality
  • Purlin erection is easier than others
  • Assured dimensions and straightness
  • No side drilling/cutting required
  • Saving in Steel up to 40%
  • Fast to erect and easy handling
  • Saving in construction cost up to 30%
  • Ability to span length
  • Low transportation cost due to reduced weight
  • Close tolerances on sectional dimensions owing to process of cold roll forming
  • Saving up to 35-40% in weight and 20% in cost when compared to hot rolled purlins

Benefits

  • Provision of 13mtr length lead to no wastage and helps in fast installation
  • Light weight reduces handling and transportation cost
  • Saves steel upto 40%
  • Fast to erect and easy to handle
  • Saves construction cost and time
  • No site drilling / cutting required
  • Supplied in exact length and pre punched holes to reduce wastage of steel and fabrication cost

Specifications

Web Flange Lip Thickness
80 60 20 1.6 to 3mm
100 60 20 1.6 to 3mm
125 60 20 1.6 to 3mm
150 60 20 1.6 to 3mm
160 60 20 1.6 to 3mm
180 60 20 1.6 to 3mm
190 60 20 1.6 to 3mm
200 70 20 1.6 to 3mm
230 80 20 1.6 to 3mm
250 70 20 1.6 to 3mm
280 60 20 1.6 to 3mm
300 50 20 1.6 to 3mm
